MP10 (1000W)
Wherever you need power
Capacity: 1176Wh (48V/ 24500mAh)
-
-
• 1000W rated output with 1176Wh battery capacity
• High-quality LiFePO4 batteries provide better performance and safety
• 4000+ battery cycle life brings longer product service life
• Various output ports can power different devices
• High AC charging power 800W, charge your unit quickly
• DC input range 12-45V can support car charger and solar panel charging
• UPS function, standard switching time within 10ms
• Suitable for wide ambient temperature
• Compact and portable, easy to carry and move
隐藏域元素占位
- Overview
- Specifications
- Downloads
- Support
- 概要
Expand All
GENERAL INFO | |||||||
Model |
MP10 |
||||||
Rated Power | 1000W (Max.) | ||||||
Peak Power | 2000W | ||||||
Battery Capacity | 1176Wh (48V / 25600mAh) | ||||||
Battery Type | BYD LiFePO4 Battery (4000+cycles to 80% EOL) | ||||||
Dimensions (L*W*H) | 315 × 230 × 270mm | ||||||
Net Weight | 14.2kg | ||||||
Output | |||||||
USB-A * 2 | 5V / 3.0A, 9V / 2.0A, 12V / 1.5A, 18W (Max.) | ||||||
USB-A * 2 | 5V / 3.0A, 15W (Max.) | ||||||
USB-C1 | 5V / 3.0A, 9V / 3.0A, 12V / 3.0A, 15V / 2.0V, 20V / 2.0A, 40W (Max.) | ||||||
USB-C2 | 5V / 3.0A, 9V / 2.0A, 12V / 1.5A, 18W (Max.) | ||||||
All USB Output | 109W (Max.) | ||||||
DC 5521 * 2 | 12V / 5.0A, 60W (Max.) | ||||||
Cigarette Lighter | 12V / 10.0A, 120W (Max.) | ||||||
Cigarette Lighter + DC5521 | 120W (Max.) | ||||||
AC Output *2 | 120VAC, 60Hz, 1000W (Max.) Pure Sine Wave | ||||||
Light | 3W | ||||||
Input | |||||||
AC Input | 100V-130V AC, 50/60Hz, 800W (Max.) | ||||||
XT60 Input | 12VDC – 45VDC, 200W (Max.) (Support Car Charger / Sloar Panel) | ||||||
ENVIRONMENTAL OPERATING TEMPERATURE | |||||||
Charge Temperature | Discharge: -20°C to 45°C; Charge: 0°C to 45°C | ||||||
Storage Temperature | -20°C to 45°C |
Specifications are subject to change without notice, and all product drawings are for reference only. Consult MARSRIVA for the latest design and specifications.
GENERAL INFO | |||||||
Model |
MP10 |
||||||
Rated Power | 1000W (Max.) | ||||||
Peak Power | 2000W | ||||||
Battery Capacity | 1176Wh (48V / 25600mAh) | ||||||
Battery Type | BYD LiFePO4 Battery (4000+cycles to 80% EOL) | ||||||
Dimensions (L*W*H) | 315 × 230 × 270mm | ||||||
Net Weight | 14.2kg | ||||||
Output | |||||||
USB-A * 2 | 5V / 3.0A, 9V / 2.0A, 12V / 1.5A, 18W (Max.) | ||||||
USB-A * 2 | 5V / 3.0A, 15W (Max.) | ||||||
USB-C1 | 5V / 3.0A, 9V / 3.0A, 12V / 3.0A, 15V / 2.0V, 20V / 2.0A, 40W (Max.) | ||||||
USB-C2 | 5V / 3.0A, 9V / 2.0A, 12V / 1.5A, 18W (Max.) | ||||||
All USB Output | 109W (Max.) | ||||||
DC 5521 * 2 | 12V / 5.0A, 60W (Max.) | ||||||
Cigarette Lighter | 12V / 10.0A, 120W (Max.) | ||||||
Cigarette Lighter + DC5521 | 120W (Max.) | ||||||
AC Output *2 | 230VAC, 50Hz, 1000W (Max.) Pure Sine Wave | ||||||
Light | 3W | ||||||
Input | |||||||
AC Input | 200VAC – 240VAC, 50/60Hz, 800W (Max.) | ||||||
XT60 Input | 12VDC – 45VDC, 200W (Max.) (Support Car Charger / Sloar Panel) | ||||||
ENVIRONMENTAL OPERATING TEMPERATURE | |||||||
Charge Temperature | Discharge: -20°C to 45°C; Charge: 0°C to 45°C | ||||||
Storage Temperature | -20°C to 45°C |
Specifications are subject to change without notice, and all product drawings are for reference only. Consult MARSRIVA for the latest design and specifications.
